Specifications
Every figure, verified
Dimensions, rig, power, tankage and deck plans — the yacht on paper.
The Detail
Specification
Dimensions
- Builder
- Sunreef Yachts
- Model
- Sunreef 80 (sail)
- Year
- 2022
- Length overall
- 78'3" / 23.87 m
- Beam
- 37'8" / 11.53 m
- Draft
- 7'2" / 2.2 m
- Living space
- 340 m² / 3,660 ft²
- Guests
- 8
- Guest cabins
- 4 — master + 3, all ensuite
- Crew
- 4 — 2 crew cabins
- Hull
- E-glass sandwich
- Decks
- Teak — deck, cockpit, skirts, flybridge
Performance
- Engines
- 2 × John Deere 6068SFM85, 280 hp
- Engine hours
- Port 750 (replaced March 2024) · Starboard 3,094
- Cruising speed
- 8 knots
- Fuel
- 2 × 3,000 L
- Propellers
- Folding, with shaft rope cutters
- Bow thrusters
- 2 × electric
Power & Systems
- House batteries
- Lithium house bank
- Generators
- 2 × 27 kVA (4,132 h port / 4,585 h starboard)
- Solar
- 580 W
- Inverting power
- 20,000 W @ 230 V · 9,000 W @ 110 V
- Air conditioning
- 166,000 BTU/h, including forepeaks
- Watermaker
- 280 L/h
- Fresh water
- 1,600 L · 2 × 100 L heaters
- Lightning protection
- Elna system — insurer approved
Sails & Rig
- Sailmaker
- Bryt Sails
- Headsails
- Code Zero (new UV protection) · Genoa (UV strip renewed)
- Mainsail
- Reefing clew points reinforced beyond factory specification
- Winches
- Electric primary and secondary (Lewmar)
- Helms
- Navigation station + flybridge, carbon 1,100 mm wheel
- Electronics
- Raymarine gS-series — 15.4" and 12.1" MFDs, 4 kW radar, Evolution autopilot with gyrocompass, GPS, dual-station VHF/DSC
Ground Tackle & Safety
- Anchor
- 100 kg ULTRAmarine + 120 m chain · secondary 90 kg FOB Rock
- Windlass
- 3,500 W
- Commercial coding
- MCA Category 2 (Red Ensign)
- Life rafts
- Rated for 16 persons
Deck Plans
Four decks, drawn to scale
Sunreef 80 general arrangement. Endless Horizon II, hull as built.
Tap to open full screen — pinch to zoom, or turn your phone sideways.
Maintained, not just owned
Recent investment
2024
Port engine replaced; now 750 hours.
Sails
Code Zero fitted with new UV protection; genoa UV strip renewed; mainsail reefing clew points reinforced beyond factory specification, by Bryt Sails.
Lightning protection
Elna prevention system installed and approved by the vessel's insurer.
Anchoring
Stainless reinforcement plates and a larger anchor, eliminating the hull-contact issue carried over from the first Endless Horizon.
Tender lift
Upgraded from 50 amp to 150 amp and reinforced for the largest tender the platform will take.
Boom roller system
Upgraded to eliminate mainsail control-line chafe.
Galley relocation
Moved up into the salon for better flow and clearer owner/guest separation.
Yard work
Cutless bearings, antifouling and anodes renewed.
